3.0-3.5t Telehandler
Key words:
Classification:
Telescopic Arm Forklift
Hotline:
3.0-3.5t Telehandler
1. Flexible Steering Modes
Three steering modes, including: front wheel steering (default mode), four-wheel steering, crab mode; switched via the shift switch.
Small turning radius, suitable for working in narrow areas; when using four-wheel steering, the turning radius is 4 meters.
2. Adjustments for Off-Road Driving
The rear axle can adapt to ground oscillation, with an oscillation angle of +5°.
3. Hydraulic Control System
Uses a closed variable system + load-sensitive system, energy-saving and environmentally friendly, can be freely controlled.
Mobile independent closed variable system, energy-saving; the load system uses an open load sensing system.
4. Comprehensive Electrical Control Protection
Added rollover limiter, which can alert and cut off operations on the vehicle during excessive operation to prevent safety accidents.
Electronic throttle control, movable, able to increase power with speed and adapt to off-road driving needs.
The onboard operation belt is equipped with an onboard stop button, which will automatically stop the onboard operation if the operator accidentally releases their hand.
5. Cabin Design
Spacious interior space, luxurious atmosphere, wide field of vision.
Equipped with multiple connected entertainment players and several storage spaces.
Main Technical Parameter Table
| S/N | Name of performance project | Performance or parameters | Remarks | ||
| HZTH3007 | HZTH3507 | ||||
| 1 |
Outline dimension |
Length (mm) | 5000 | 5000 |
Remove the fork |
| Width (mm) | 2220 | 2220 | |||
| Height (mm) | 2410 | 2410 | |||
| 2 | Curb weight (kg) | 7150 | 7350 | ||
| 3 | Hydraulic System Pressure (MPa) | 30 | 30 | ||
| 4 | Hydraulic System Flow (L/min) | 145 | 145 | ||
| 5 | Hydraulic Fuel Tank Capacity (L) | 120 | 120 | ||
| 6 | Engine | Brand | QSB3.9-C100-30 | QSB3.9-C100-30 | |
| 7 | Power (kw@rev) | 74/2200 | 74/2200 | ||
| 8 | Torque (N@rev) | 480/1600 | 480/1600 | ||
| 9 | Maximum Travel Speed (km/h) | 25 | 25 | ||
| 10 | Gradeability (°) | 40% | 40% | ||
| 11 | Departure Angle (°) | 33 | 33 | ||
| 12 | Swing angle of rear axle frame (°) | 5 | 5 | ||
| 13 | Tire specification | 12-16.5 12pr | 12-16.5 12pr | ||
